Diary of a spaCy project: Predicting GitHub Tags

· by Vincent D. Warmerdam & Sofie Van Landeghem · ~14 min. read

One could learn how an oven works, but that doesn’t mean that you’ve learned how to cook. Similarly, one could understand the syntax of a machine learning tool, and still not be able to apply the technology in a meaningful way. That’s why in this blogpost I’d like to describe some topics that surround the creation of a spaCy project that isn’t directly related to syntax and instead relate more to “the act” of doing an NLP project in general.

As an example use-case to focus on, we’ll be predicting tags for GitHub issues. The goal isn’t to discuss the syntax or the commands that you’ll need to run. Instead, this blog post will describe how a project might start and evolve. We’ll start with a public dataset, but while working on the project we’ll also build a custom labelling interface, improve model performance by selectively ignoring parts of the data and even build a model reporting tool for spaCy as a by-product.

Motivating example

Having recently joined Explosion, I noticed the manual effort involved in labelling issues on the spaCy GitHub repository. Talking to colleagues who maintain the tracker on a daily basis, they mentioned that some sort of automated label suggester could be helpful to reduce manual load and enforce more labelling consistency.

This repository has over 5000 issues, most of which have one or more tags attached that the project’s maintainers have added. Some of these tags, for example, indicate that it’s about a bug, while others show there’s an issue in the documentation.

I discussed the idea of predicting tags with Sofie, one of the core developers of spaCy. She was excited by the idea and would support the project as the “domain expert” who could explain the details of the project whenever I would miss the relevant context.

After a small discussion, I verified some important project properties.

  1. There was a valid business case to explore. Even if it was unclear what we should expect from a model, we did recognize that having a model that could predict a subset of tags could be helpful.
  2. There is a labelled dataset available with about 5000 examples, that could be downloaded easily from the GitHub API. While the labels may not be perfectly consistent, they should certainly suffice as a starting point.
  3. The problem was well defined in the sense that we could translate the problem down to a text categorization task. The contents of a GitHub issue contained text that we needed to classify into a set of non-exclusive classes that were known upfront.

This information was enough for me to get started.

Step 1: project setup

To get an overview of the steps needed in my pipeline, I typically start out by drawing on a digital whiteboard. Here’s the first drawing I made.

A first drawing of the process
A first sketch of the required steps.

To describe each step in more detail:

  1. First, a script downloads the relevant data from the GitHub API.
  2. Next, this data would need to be cleaned and processed. Between the sentences describing the issue, there would also be markdown and code blocks, so some sort of data cleaning step is required here. Eventually, this data needed to be turned into the binary .spacy format so that I can use it to train a spaCy model.
  3. The final step would be to train a model. The hyperparameters would need to be defined upfront in a configuration file and the trained spaCy model would then be saved on disk.

This looked simple enough, but the “preprocess” step felt a bit vague. So I expanded that step.

More detailed drawing of the preprocess step
More details on how to preprocess.

I decided to make the distinction between a couple of phases in my preprocess step.

  1. First, I decided that I needed a clean step. I wanted to be able to debug said cleaning step so that meant that I also needed an inspectable file with clean data on disk. I usually also end up re-labelling some of the data with Prodigy when I’m working on a project and a cleaned .jsonl file would allow me to update my data at the start of the pipeline.
  2. Next, I needed a split step. I figured I might want to run some manual analytics on the performance on the train and validation set. That meant that I needed the .jsonl variants of these files on disk as well. The reason I couldn’t use the .spacy files for this was that the .jsonl files can contain extra metadata. For example, the raw data had the date when the issue was published, which would be very useful for sanity checks.
  3. Finally, I’d need a convert step. With the intermediate files ready for potential investigation, the final set of files I’d need is the .spacy versions of the training and validation sets.

Reflection

Implementing the code I need for a project is a lot easier when I have a big-picture idea of what features are required. That’s why I love doing the “solve it on paper first” exercise when I’m starting. The drawn diagrams don’t just help me think about what I need; they also make for great documentation pieces, especially when working with a remote team.

When the drawing phase was done, I worked on a project.yml file that defined all the steps I’d need.

What did the project.yml file look like?

A project.yml file in spaCy contains a description of all the steps, with associated scripts, that one wants to use in a spaCy project. The snippet below omits some details, but the most important commands I started with were:

workflows:
  all:
    - download
    - clean
    - split
    - convert
    - train
  preprocess:
    - clean
    - split
    - convert

commands:
  - name: 'download'
    help: 'Scrapes the spaCy issues from the Github repository'
    script:
      - 'python scripts/download.py raw/github.jsonl'

  - name: 'clean'
    help: 'Cleans the raw data for inspection.'
    script:
      - 'python scripts/clean.py raw/github.jsonl raw/github_clean.jsonl'

  - name: 'split'
    help: 'Splits the downloaded data into a train/dev set.'
    script:
      - 'python scripts/split.py raw/github_clean.jsonl assets/train.jsonl
        assets/valid.jsonl'

  - name: 'convert'
    help: "Convert the data to spaCy's binary format"
    script:
      - 'python scripts/convert.py en assets/train.jsonl corpus/train.spacy'
      - 'python scripts/convert.py en assets/valid.jsonl corpus/dev.spacy'

  - name: 'train'
    help: 'Train the textcat model'
    script:
      - 'python -m spacy train configs/config.cfg --output training/
        --paths.train corpus/train.spacy --paths.dev corpus/dev.spacy --nlp.lang
        en'
What did the folder structure look like?

While working on the project file, I also made a folder structure.

📂 spacy-github-issues
┣━━ 📂 assets
┃   ┣━━ 📄 github-dev.jsonl (7.7 MB)
┃   ┗━━ 📄 github-train.jsonl (12.5 MB)
┣━━ 📂 configs
┃   ┗━━ 📄 config.cfg (2.6 kB)
┣━━ 📂 corpus
┃   ┣━━ 📄 dev.spacy (4.0 MB)
┃   ┗━━ 📄 train.spacy (6.7 MB)
┣━━ 📂 raw
┃   ┣━━ 📄 github.jsonl (10.6 MB)
┃   ┗━━ 📄 github_clean.jsonl (20.3 MB)
┣━━ 📂 recipes
┣━━ 📂 scripts
┣━━ 📂 training
┣━━ 📄 project.yml (4.1 kB)
┣━━ 📄 README.md (1.9 kB)
┗━━ 📄 requirements.txt (95 bytes)

The training folder would contain the trained spaCy models. The recipes folder would contain any custom recipes that I might add for Prodigy and the scripts folder would contain all the scripts that handle the logic that I drew on the whiteboard.

Step 2: learning from a first run

With everything in place, I spent a few hours implementing the scripts that I needed. The goal was to build a fully functional loop from data to model first. It’s much easier to iterate on an approach when it’s available from start to finish.

That meant that I also did the bare minimum for data cleaning. The model received the raw markdown text from the GitHub issues, which included the raw code blocks. I knew this was sub-optimal, but I really wanted to have a working pipeline before worrying about any details.

  1. Once the first model had been trained, I started digging into the model and the data. From that exercise, I learned a few important lessons. First, there are 113 tags in the spaCy project, many of which aren’t used much. Especially the tags that relate to specific natural languages might only have a few examples.
  2. Next, some of the listed tags were not going to be relevant, no matter how many training examples there were. For example, the v1 tag indicates that the issue is related to a spaCy version that’s no longer maintained. Similarly, the wontfix tag indicates a deliberate choice from the project maintainers, and the reasoning behind that choice will typically not be present in the first post of the issue. Any algorithm realistically has no way of predicting this kind of “meta” tag.
  3. Finally, the predictions out of spaCy deserved to be investigated further. A spaCy classifier model predicts a dictionary with label/confidence pairs. But the confidence values tend to differ significantly between tags.

I wanted to prepare for my next meeting with Sofie. So the next step was to make an inventory of what we might be able to expect out of the current setup.

Step 3: build your own tools

To better understand the model performance, I decided to build a small dashboard that would allow me to inspect the performance of each tag prediction individually. If I understand the relation between the threshold of a tag and the precision/recall performance, then I could use that in my conversation with Sofie to confirm if the model was useful.

I proceeded to add a script to my project.yml file that generated a few interactive charts in a static HTML file. That way, whenever I’d retrain my model, I’d be able to automatically generate an interactive index.html file that allowed me to play around with threshold values.

Here’s what the dashboard would show me for the docs tag.

More detailed drawing of the preprocess step
Two histograms, one for the Train set and another one for the Validation. These histograms show much "mass" of the tagger/non-tagged issues would be associated with a threshold value.
More detailed drawing of the preprocess step
Two line charts, one for the train set and another for the validation set. These line charts show a chosen threshold value's precision/recall/accuracy metrics. These charts made it easy for me to make a trade-off between precision and recall for each tag.

With this dashboard available, it was time to check back in with Sofie to discuss which tags might be most interesting to explore further.

Step 4: reporting back

The meeting that followed with Sofie was exciting. As a maintainer, she had a lot of implicit knowledge that I was unaware of, but because I was a bit closer to the data at this point, I also knew things that she didn’t. The exchange was very fruitful, and a couple of key decisions got made.

  1. First, Sofie pointed out that I was splitting my train/test sets randomly and that this was not ideal and that I should take the recent issue data as my test set. The main reason was that the way the issue tracker was used has changed a few times over time. The project gained new tags over time, new conventions as new maintainers joined the project and the repository also recently added GitHub discussions, which caused a lot of issues to become discussion items instead.
  2. Next, Sofie agreed that we should only focus on a subset of tags. We decided to only look at tags that appear at least 180 times.
  3. Finally, I asked Sofie how much I could trust the training data. After a small discussion, we agreed it would be good to double-check some examples because it’s possible that some of the tags weren’t assigned consistently. While the spaCy core team has been very stable over the years, the specific set of people doing support has varied a bit over time. I had also spotted some issues that didn’t have any tags attached, and Sofie agreed that these were good candidates to check first.

I agreed to pick up all of these items as the next steps.

Step 5: lessons from labelling

I adapted the scripts that I had and moved on to create a custom labelling recipe for Prodigy. I wanted the issues to render just like they would render on Github so I took the effort of integrating the CSS that GitHub uses to render markdown.

Prodigy layout
It looks just like Github!

I was happy with how the issue was rendered, but I quickly noticed that some of these issues are very long. I was mindful of my screen real-estate which is why I did some extra CSS work to get the entire interface loaded in a two-column layout.

Two column Prodigy layout
Two columns is better for the screen real-estate.

This two-column layout was just right for my screen. The images would render too, which was a nice bonus of the setup.

That meant now it was ready to label. So I checked the data by trying out a few tactics.

  1. I started by looking at any examples that didn't have any tags attached. Many of these examples turned out to be short questions more related to the usage (and non-usage) of the library. These would include things like "can I get spaCy to run on mobile?". It'd often be about an example where the tokenizer or the part of speech tagger did something unexpected. Many of these examples didn't describe an actual bug but rather described an expectation of a user which therefore also belongs to the "usage" tag.
  2. Next, I decided to check examples by sampling them randomly. By labelling this way, I noticed that many examples with the "bug" tag missed an associated tag that would highlight the relevant part of the codebase. After doing some digging, I learned that, for example, the feat / matcher tag was introduced much later than the bug label. That meant that many relevant tags could be missing from the dataset if the issue appeared before 2018.
  3. line chart
    The matcher feature tag appears much later compared to the "bug" tag.

  4. Finally, I figured I'd try one more thing. Given the previous exercise, I felt that the presence of a tag was more reliable than the absence of a tag. So I used the model that I had trained and had it try to predict the feat / matcher tag. If this tag were predicted while it was missing from an example, it'd be valid to double-check. There were 41 of these examples, compared to 186 labelled instances that had a feat / matcher tag. After labelling, I confirmed that 37/41 were wrongly missing the tag. It also turned out that 29/37 of these examples predate 2018-02, which was when the `feat / matcher` label was introduced.

Given these lessons, I decided to reduce my train set. I’d only take examples after 2018-02 to improve the consistency. Just doing this had a noticeable effect on my model performance.

EpochStepScore BeforeScore After
050057.9761.31
0100063.1066.61
0150064.8570.99
0200067.4773.65
0250071.5375.77
1300071.7977.93
1350073.2079.11

This was an interesting observation; I only modified my training data and didn’t change the test data that I use for evaluation. That means that I improved the model performance by iterating on the data instead of the model.

I decided to label some more examples that might be related to the feat / matcher tag before training the model one more time. I made subsets by looking for issues that had the term “matcher” in the body. This gave me another 50 examples.

Step 6: another progress report

After training the model again, and after inspecting the threshold reports, I figured I hit a nice milestone. I zoomed in on the feat / matcher tag and learned that I could achieve:

  • a 75% precision / 75% recall rate when I select a threshold of 0.5.
  • a 91% precision / 62% recall rate when I select a threshold of 0.84

These metrics weren’t by any means “state of the art” results, but they were tangible enough to make a decision.

I presented these results to Sofie and she enjoyed the ability to consider the threshold options. It meant that we could tune the predictions without having to retrain a new model, even though the numbers were looking pretty good at the original 0.5 threshold. As far as the feat / matcher tag was concerned, Sofie considered the exercise a success.

The project could be taken further. We wondered about what other tags to prioritize next and also started thinking about how we might want to run the model in production. But the first exercise of building a model was complete, which meant that we could look back and reflect on some lessons learned along the way.

Conclusion

In this blog post, I’ve described an example of how a spaCy project might evolve. While we started with a problem that was well defined, it was pretty hard to predict what steps we’d take to improve the model and get to where we are now. In particular:

  • We analyzed the tags dataset which taught us that certain dates could be excluded for data consistency.
  • We created a custom labelling interface, using the CSS from GitHub, which made it convenient to improve and relabel examples in our training data.
  • We made a report that was specific to our classification task, which allowed us to pick threshold values to suit our needs.

All of these developments were directly inspired by the classification problem that we tried to tackle. For some subproblems, we were able to use pre-existing tools, but it was completely valid to take the effort to make tools that are tailored to the specific task. You could even argue that taking the time to do this made all the difference.

Imagine if instead, we had put all of the efforts into the model. Is it really that likely that we would have been in a better state if we had tried out more hyperparameters?

The reason why I like the current milestone is because the problem is much better understood as a result. That’s also why my interactions with Sofie were so valuable! It’s much easier to customize a solution if you can discuss milestones with a domain expert.

This lesson also mirrors some of the lessons we’ve learned while working on client projects via our tailored pipelines offering. It really helps to take a step back to consider an approach that is less general in favor of something a bit more bespoke. Many problems in NLP won’t be solved with general tools, they’ll need a tailored solution instead.

Oh, and one more thing …

The custom dashboard I made in this project turned out to be very useful. I also figured that the tool is general enough to be useful for other spaCy users. That’s why I decided to open-source it. You can pip install spacy-report today to explore threshold values for your own projects today!
